Behavioral Pattern Programming

Uncover meaningful and interesting patterns in your data and transform the findings into pattern recognition programs with just a few lines of code

Email address is wrong, please try again

Thanks for subscribing. We will send an email when your invite is ready!

Spread the word about Braincast ❤️



People and Systems

PATTERN SYSTEM

Phenomena, in reality, are reflected in data when collected appropriately. Still, It is highly challenging to express to a computer what to search for to uncover a phenomenon. Mainly due to the fact it is scattered in small pieces of information across time in a growing haystack of data. Behavioral patterns are a simple though efficient approach to describe and understand the behavioral aspects of every phenomenon.



Programmable Patterns

PATTERN

Uncover meaningful patterns using a programmable approach for pattern learning, recognition, and fine-tuning. The Pattern Description Language is the way patterns are expressed in a human-understandable language which results in white-box models with inherent explainability. Agnostic to data source formats, complexity, and supports the fusion of multiple sources.



Built for Developers

API INTERFACE

Easy to use API for quickly building prediction, classification, anomaly detection, and forecasting AI tasks. Patterns are versioned with change tracking which makes AI development manageable. Quickly build a POC in days with no strings attached enjoying our free tier plan. Once you are satisfied with the results and the code is ready, switch to production in one click.




Pattern Recognition Demo


Logic

The NBA dataset seasonal player stats has the player’s name, position, age, team, player, PER, and BPM.

The behavioral pattern of a superstar is:

  • Check every three consecutive seasons
  • Player is in the top five in the team and played the most minutes (MP)
  • Player started at above 80% of the games he played (GS/G)
  • Player wins shares (WS) is above the median of all players in the league
  • Player Efficiency Rating (PER) in all three seasons is above 18 and in the last season is above 20
  • Player contribution to the team (BPM) increases over the seasons and is always one point above the league average
  • Player with the highest average value over all three seasons, compared to all other players
Live Demo
Source Code
const bcToken = "my_braincast_token";
const bcSecretKey = "my_secret_api_key";
const bc = BC.createClient(bcToken, bcSecretKey);
// assume the following four variables represent values specified by the user of your application:
const minYearFromUser = 1990;
const maxYearFromUser = 2019;
const positionFromUser = "center";
const teamFromUser = "Lakers";

const BasketballReferenceOpenAPITemplate = {
	openAPISpec: Examples.OpenAPI.JSON.NBA, // the Open API Specification (OAS) of a REST data source for accessing the churn user data
	path:"/query",  // the HTTP endpoint to use from the OAS spec
	operation:"get",  // the HTTP method to use
	params:{     // required values for parameters specified in the OAS
		"apikey":     "AKIAIOSFODNNSLOE:Yxg83MZaEgh3OZ3l0rLo5RTX11o="
	}
};

//
// define and validate data sources
//
let stream = bc.Datastore.getStream("NBA.Example.Seasons");
if (!stream) {
	stream = bc.Datastore.defineStream(
		{
			"source": "NBA.Example.Seasons",//source name
			"adapter": BC.Utils.SourceAdapters.createREST(BasketballReferenceOpenAPITemplate),// REST adapter to fetch data created from the data source's Open API Specification
			"record": { // provide an object to specify which attributes of the records being fetched from the source should be used (if omitted, all attributes will be used) - each property is an attribute and the value is that attribute's description:
				"Year":		     	"the season",
				"Player":	     	"player's full name",
				"Pos":		     	"player's position",
				"Tm":		     	"team's three letter name",
				"G":		     	"the number of games the player participated in",
				"GS":		     	"the number of games the player started in",
				"WS":		     	"the player's Wins Shares score",
				"MP":		     	"the amount of minutes played by the player",
				"PER":		     	"the player's Player Efficiency Rating score",
				"BPM":		     	"the player's Box +/- score",
				"rankTeamMP":    	"the player's minutes played (MP) ranking compared to other players in his team and for same year",
				"percentileYearWS": "the player's wins share (WS) percentile compared to other players in the league for the same year"
			},
			"filter": {"where":"Year >= 1985"} // the filter for this source specifying that only the data after 1985 should be consumed
		}
	);
	if (!stream || !stream.validate()) {
		throw "Example stream cannot be accessed, reason: " + stream.validationErrorMsg;
	}
}

//
// build scanner
//
if (!stream.getScanner("myBestNBAPlayerTheory")) { // the name of the scanner and the patterns inside the scanner are in the namespace of the stream
	let scanner = stream.createScanner(
		{// make user specified values available for the scanner as scanner variables that can be accessed via the vars keyword (don't forget to update their values every time you scan the stream, e.g. for different user queries)
			"minYearFromUser": undefined,
			"maxYearFromUser": undefined,
			"positionFromUser": undefined,
			"teamFromUser": undefined
		}
	);
	scanner.addConstraint("consecutiveSeasons", // constraint name
		function(curSequence) {
			for (let i = 1; i < curSequence.records.length; i++) {
				if (curSequence.records[i].Year - curSequence.records[i-1].Year !== 1) {
					return false;
				}
			}
			return true;
		},
		"seasons are consecutive"// explanation
	);
	scanner.addConstraint("3Seasons",
		function(curSequence) {
			return  curSequence.records.length === 3;
		},
		"there are exactly 3 seasons"// explanation
	);
	scanner.addConstraint("samePlayer",
		function(curSequence) {
			return  curSequence.records.every(record => record.Player === curSequence.records[0].Player);
		},
		""
	);
	scanner.addConstraint("sameTeam",
		function(curSequence) {
			return  curSequence.records.every(record => record.Tm === curSequence.records[0].Tm);
		},
		"the player played for the same team in every season"
	);
	scanner.addConstraint("rankedTop5",
		function(curSequence) {
			let lastSeason = curSequence.records[curSequence.records.length-1];
			return  lastSeason.rankTeamMP <= 5;
		},
		"the player was ranked among the top 5 players in his team who played the most minutes (MP) during the last season"
	);
	scanner.addConstraint("startedInOver80%",
		function(curSequence) {
			let lastSeason = curSequence.records[curSequence.records.length-1];
			return  lastSeason.GS / lastSeason.G > 0.8;
		},
		"the player started in more than 80% of the games he played (GS/G) during the last season"
	);
	scanner.addConstraint("winSharesAboveMedian",
		function(curSequence) {
			return  curSequence.records[curSequence.records.length-1].percentileYearWS > 50;
		},
		"the player's win shares (WS) score in the last season was above the median of all players in the league"
	);
	scanner.addConstraint("everyPER>18",
		function(curSequence) {
			return 	curSequence.records.every(record => record.PER > 18) ;
		},
		"the player's efficiency rating (PER) was above 18 in every season"
	);
	scanner.addConstraint("lastPER>20",
		function(curSequence) {
			return 	curSequence.records[curSequence.records.length-1].PER > 20;
		},
		"the player's efficiency rating (PER) was above 20 in the last season"
	);
	scanner.addConstraint("everyBPM>1",
		function (curSequence) {
			return curSequence.records.every(record => record.BPM > 1);
		},
		"the player's contribution to the team, measured by box +/- (BPM), was 1 point above the league-average (for which BPM = 0)"
	);
	scanner.addConstraint("nonDecreasingBPM",
		function (curSequence) {
			for (let i = 1; i < curSequence.records.length; i++) {
				if (curSequence.records[i].BPM < curSequence.records[i-1].BPM) {
					return false;
				}
			}
			return true;
		},
		"the player's contribution to the team, measured by box +/- (BPM), didn't decrease from one season to the next"
	);
	function bpmAvg(pattern) {
		return pattern.records.reduce(function (sum, record) {
			return sum + record["BPM"];
		}, 0) / (pattern.records.length || 1);
	}
	scanner.addConstraint(
		BC.Meta.Functions.Constraints.newMaximalValueConstraint(
			"highestBPMAvg",
			bpmAvg, // evaluator function - the sequence for which this function's value is maximal will be selected out of all sequences satisfying all other constraints
			"having the greatest contribution to the team, measured by the average box +/- (BPM) over all seasons"
	));
	scanner.addConstraint("constraintUserInput",
		function (curSequence) {
			let lastSeason = curSequence.records[curSequence.records.length-1];
			return 	((vars.minYearFromUser || lastSeason.Year >= vars.minYearFromUser) &&
					 (vars.maxYearFromUser || lastSeason.Year <= vars.maxYearFromUser) &&
					 (vars.positionFromUser || lastSeason.Position === vars.positionFromUser) &&
					 (vars.teamFromUser || lastSeason.Team === vars.teamFromUser));
		},
	"satisfy the user's request parameters: "+toUserRequestString(vars.minYearFromUser,vars.maxYearFromUser,vars.positionFromUser,vars.teamFromUser)
	);

	if (!scanner.validate()) {
		throw "Scanner not configured properly, reason: "+scanner.validationErrorMsg;
	}

	scanner.save("myBestNBAPlayerTheory", true); // override if such exists
}

// Update the user specified values available to the scanner (in case the scanner was fetched from backend):
scanner.vars = {
	"minYearFromUser": minYearFromUser,
	"maxYearFromUser": maxYearFromUser,
	"positionFromUser": positionFromUser,
	"teamFromUser": teamFromUser
};

// run our scanner on the stream
result = stream.scan("myBestNBAPlayerTheory");
userRequirements = toUserRequestString(minYearFromUser,maxYearFromUser,positionFromUser,teamFromUser);
alert("The best NBA player matching your requirements ("+userRequirements+") is "+result+ ".");

//
// helper functions:
//
function toUserRequestString(minYearFromUser,maxYearFromUser,positionFromUser,teamFromUser) {
	return	minYearFromUser?`Year >= ${minYearFromUser} `:""+
	maxYearFromUser?`Year <= ${maxYearFromUser} `:""+
	positionFromUser?`Position = ${positionFromUser} `:""+
	teamFromUser?`Team = ${teamFromUser}`:"";
}

Patterns Everywhere

One Algorithm for Many Use-cases


LOG FILE

Devops

Optimize CI process, predict service degradation, detect deviations in billing…

WORLDWIDE COVERAGE

IoT

Smart cities, predictive maintenance, supply chain optimization, process optimization…

WEB ANALYTICS

Marketing

Segmentation, churn prediction, next best offer, journey optimization…

STARTUP ROCKET

User Experience

User experience personalization, smart A/B testing, real-time channel selection…

PLAN

Back-office

Employee performance optimization, call center optimization…

CONTRACT

Fintech

Credit scoring, robo-trading, fraud detection, anti money laundering…

Trustworthy AI



AI is at crossroads due to the black-box nature of machine learning based decision making process. We believe in transparency, human control, and visibility into AI models which ensures a safer path into the future. The patterns description language offers unparalleled clarity and control into AI.
